Both processes make precision metal parts. The wrong choice can cost you weeks of lead time or tens of thousands in unnecessary tooling. Here is how to tell them apart, and how to pick the right one for your project.
Brief Definitions
Pressure die casting forces molten metal into a hardened steel die at high speed and pressure, typically 1,500 to 25,000 PSI. The metal solidifies in seconds. The die opens, the part ejects, and the cycle repeats. This is a fundamentally high-throughput process.
Investment casting (also called lost-wax casting) starts with a wax pattern shaped exactly like the finished part. The pattern is coated in a ceramic shell, the wax is melted out, and molten metal is poured in. The shell is broken away after solidification. The process is slower but capable of extremely fine detail and complex geometry.
Speed vs. Detail: Where Each Process Wins
Die casting can produce 10 to 50 parts per minute for small zinc parts. Cycle times for aluminum die castings typically run 30 to 120 seconds. Investment casting, by contrast, takes days: wax injection, shell building, burnout, casting, and finishing each add time.
But speed is not everything. Investment casting handles geometries that die casting cannot touch: true undercuts, thin walls down to 0.5mm, internal passages, and fine surface detail. If your part has complex internal geometry or needs a material like steel or a superalloy, investment casting is often the only practical choice.
The Cost Breakpoint: Volume Is the Deciding Factor
Die casting tooling (the steel die) typically costs $5,000 to $50,000+. That cost must be amortized over your production run. Investment casting tooling (the wax injection die) is cheaper, often $500 to $5,000, but per-part costs are higher.
● Under 1,000 parts: Investment casting is often cheaper on a total cost basis. Tooling is lower, and the premium per-part cost does not add up to much at low volumes.
● 1,000 to 5,000 parts: This is the crossover zone. Run the numbers for your specific part size and complexity. Neither process has a clear advantage.
● Above 5,000 parts: Die casting dominates. The tooling cost is spread across enough parts that per-unit economics are hard to beat.
Materials: Not All Metals Work in Both Processes
Die casting works best with non-ferrous alloys that melt at lower temperatures: aluminum, zinc, and magnesium. The high-pressure dies are made from tool steel, and ferrous materials at die casting temperatures would damage the die.
Investment casting works with virtually any metal: carbon steel, stainless steel, tool steel, titanium, and high-temperature superalloys. If your part is steel, investment casting is almost always the answer.
